Page 84 - 2025 Premier Digital Fence Catalog

High Tensile Tools
More HT
tool options
pp. 87–88
Hands Free!
Easily tie off/staple wire
Stay Holder
Fits between post and brace. Slides
easily into position to hold support. For
either horizontal or angled brace supports.
Heavy gauge galvanized steel. 6-3/4"L
x 5"W.
Stay Holder , 0.78 lb. ..................................#408307 $5.10
Wire Twister
Useful tool for neat and easy wire tying.
Compact and handy to carry. Provides
the necessary leverage to successful twist,
terminate or splice high tensile wire.
Gold passivated for increased corrosion
protection. 3"L x 1"W.
Wire Twister, 3", 0.11 lb...........................#408303 $4.00
Easy Wire Puller
Quickly and easily tensions
either smooth or woven wire
around strainer posts. Smooth
grip wire clamp prevents wire
damage. Overall length approx
26.7". Handle pipe 1" diameter.
Wire Puller, 4.50 lb. ......#408302 $102.00
Heavy Duty Stay Holder
Holds H-brace bars in place for
installation. Suitable for angle/horizontal
rails. Use one at each end of the brace.
Made of heavy gauge galvanized steel.
Corrosion resistant for years of use.
Nails not included. 8"L x 6"W.
Heavy Duty Stay Holder, 0.73 lb..............#408304 $9.00
Crimp Sleeves
12.5 gauge (2.5mm) wire crimp
sleeves. Water resistant grit adhesive for
application in all weather conditions.
For use on 1.6mm to 2.5mm fencing
wire. Container of 100.
Crimp Sleeves, 100 qty.
2.5mm, 12.5g, 0.40 lb........................... #339022 $32.00
Barbed Wire Crimp Sleeves
Barbed wire crimp sleeves. Water
resistant grit adhesive for installation
in all weather conditions.
For use on 12 gauge (2.5mm) mild steel
barbed fencing wire. Container of 50.
Barbed Wire Crimp Sleeves, 50 qty
2.5mm, 12.5g, 0.14 lb. .............................#339021 $23.50
H Brace Mistakes
•
Angles formed by horizontal bar, end post
and brace wire are wrong. Result? The end post
lifts up as you see to the right. Solutions? Either
lower the brace bar or use a longer cross bar (10 ft
or more). We now use an 8 ft long post as a brace
bar but we set it only 36" above the soil. The
brace wire attaches at the same 36" point.
•
End post too small and/or not buried deep
enough. For fences 3 to 4 ft tall, use 8" diameter
end posts. Drive or set them 4 ft deep.
•
Using floating braces. Regrettably we tried this
design. They all ultimately failed.
•
Live wires touching brace wires. When this
occurs, as it does when posts move (like those
shown at right have done), contact will occur and
the fence will short out.
Cross brace is too short and
set too high—allowing end post
to be pulled out of the ground
by the tension of wire fence.
84 STRAINRITE premier1supplies.com • 1-800-282-6631
