For 20B & B4 energizers, info online only. For all 12v energizers

102 ENERGIZER ACCESSORIES

www.premier1supplies.com

• 1-800-282-6631

New! Sealed Lead Acid Deep Cycle Batteries Rechargeable with solar panel or 2 amp 12v rechargers. Won’t leak if tipped. Does not release harmful gases. Will withstand repeated discharges (if not lower than 40% discharge). 30-day warranty. 7 amp hr, 4.75 lb...........#117251 $23.75 12 amp hr, 8.05 lb.........#121600 $37.00 18 amp hr, 15 lb............#121618 $44.00 26 amp hr, 18 lb............#121626 $68.00 33 amp hr, 30 lb............#121635 $81.00 44 amp hr, 33 lb............#121700 $101.00 66 amp hr, 51 lb............#121800 $179.00 Ground Rods and Clamp Ground rods are essential for all energizers and lightning diverters. • Allow 3 ft of ground rod per joule of energy output. • Space 3 ft rods at least 4 ft apart. • Space 6 ft rods at least 9 ft apart. Green grass vs dry soil —in dry soils use ground rods long enough to reach moist soil. 6' x 5/8" Rod, 6 lb....................#151000 $10.50 3' x 1/2" Rod, 2.10 lb...............#151200 $5.15 Rod Clamp, 0.10 lb...................#151800 $1.55 New! T Ground Rods Now easier to grasp and pull out of the soil. Galvanized. 3' x 1/2" T Rod, 3.50 lb...........#151210 $9.00 18" x 1/2" T Rod, 1.20 lb.........#151220 $4.25 Rod Clamp, 0.10 lb...................#151800 $1.55 ReCharger (2 amp) for 12 volt fence batteries Will recharge all 12v sealed lead acid batteries. To use, plug into an outlet and connect the red clip to the positive terminal and the black clip to the negative. Red light means charging and green indicates charged. The recharge rate is 1 amp/hr. So the time needed depends on battery size and on how low the battery charge level is. (Always recharge deep-cycle batteries before charge level falls below 40%.) ReCharger, 0.60 lb............................................#125012 $29.00 EzePower ™ 9-Volt Dry Batteries Lightweight (4 to 6 lb). Won’t leak, spill or damage clothes. Shippable via UPS. For 20B & B4 energizers, info online only. Not rechargeable. However, a 165 amp hr battery will last all summer long. Can be discarded like an alkaline battery. Has a 2-year shelf life if the air seal strip on the top is not removed. 55 amp hr, 3.50 lb.........................#121000 $25.75 75 amp hr, 4 lb..............................#121100 $30.00 120 amp hr, 5.50 lb.......................#121300 $42.25 165 amp hr, 6 lb............................#121500 $48.50

Inadequate grounding

is a key reason low-

impedance energizers

often lack power.

(below) Use this setup

to connect insulated wire

(see p. 136) to a ground rod.

Insulated Wire

Rod

Clamp

Fence Energizer Accessories

Easy grip “T” handle.

(below) ElectroNet 9/35/12 with a HotShock 5 energizer. Setup below shows the

energizer using a 44 aH battery—this should provide over 1 month of grazing without

needing to change/recharge the battery.
