Premier 1 2015 Fences That Work

66 / 148

K. T post C. 5-Light
Tester
D. Surge
Protector
E. Insulated
Cable
G. PowerLink 4.0 H. Conductor I. Step-In
FiberRods
J. PowerPost O. EzeReel P. EzeReel
Bracket
M. PI 21n Insulator
Up to 25 ft between line posts
Insert
T Posts 18"
B
F
E
G
I
H
K
L
M J
O
P
48"
27"
N
L. T Post Safety Cap
Q
A
66 HORSE FENCES • 1-800-282-6631
Fence diagram
Product Name Item Price Pg #
A. Battery, Plug-in or Solar Energizers.................................. 79
B. Galv. Rod 6' x 5/8", 6 lb................#151000 $10.50 102
Galv. Rod 3' x 1/2", 2.10 lb...........#151200 $5.15 102
Stainless Clamp, 0.10 lb...............#151800 $1.55 102
C. 5-Light Tester, 0.24 lb...................#134100 $11.50 103
D. Surge Protector, 0.20 lb.............. #156500 $11.50 103
E. Insulated Cable 136
F. Warning Sign, 0.06 lb....................#346000 $0.97 137
G. PowerLink 4.0, 0.20 lb................. #335500 $4.50 137
H. IntelliTape, 330', 2 lb.....................#257010 $16.00 120
IntelliTape, 660', 3 lb.................... #257020 $32.00 120
IntelliTape, 1320', 6 lb.................. #257040 $64.00 120
I. Step-In FiberRod, 48", 0.50 lb.....#321843 $3.25 125
J. PowerPost, 48", 1.10 lb............... #320830 $4.80 124
To install
Tools: Driver for steel T posts.
Time: 400 ft in an hour or less.
Skill: Minimal.
Installation:
1. Tie rope or tape to the end
post insulator.
2. Walk along fence with reel
and posts in hand. Allow rope
or tape to unroll as you walk.
3. Every 25 ft, push in a post.
Clip the rope or tape in place.
At the far end attach reel and
tension rope or tape.
4. Attach energizer. Turn it on.
Check fence for voltage.
The least expensive horse fence design.
Very easy to install and remove.
Consists of 1 or 2 strands of electrified
rope (IntelliRope® PE 4.5 or 6.0) or
IntelliTape™ stretched hand-tight between
small-diameter wood, steel or large
fiberglass posts (usually hand-driven).
Line posts are step-in plastic (left), or
Step-In FiberRods.
Uses
• To separate horses from each other.
• To fence horses out of hazards.
• To make horses easier to catch by
limiting the pasture size to only a few
days’ worth of grazing.
• To reduce under and overgrazing.
Temporary
Cost: as low as 18¢ per ft
The cost is driven by the type and
number of rope strands used and choice of
energizer. The cost per ft for line posts is
the same for any number of strands.
Other notes
• Horses must see a fence in order
to avoid it. Our conductors have
contrasting black/white colors to
ensure that they stand out visually
against all light or dark backgrounds.
• Conductivity is important. Ropes and
tapes that are poor conductors (often
found in farmstores) provide a strong
shock near the energizer and a weak
shock at the far end of the fence.
• Good conductors provide a uniform
shock and allow the use of smaller
energizers (and so less cost and risk).
• Use step-in posts—either PowerPosts
or Step-In FiberRods with harp clips.
• Must always be properly energized.
Product Name Item Price Pg #
K. Galv. Steel T post, 6', 9 lb...............#327600 $12.90 127
L. T Post Safety Cap, 0.06 lb..............#381010 $0.42 135
M. PI 21n Notched Ins., 0.08 lb...........#369200 $1.03 132
N. PI 21 Terminal Ins., 0.08 lb.............#369100 $0.45 132
O. EzeReel, 4 lb....................................#238600 $30.00 129
P. EzeReel Bracket—T posts,1.70 lb...#238501 $15.00 129
Q. SnapOn Harp Clip, 0.10 lb..............#325310 $0.19 134
Items not shown
Product Name Item Price Pg #
IntelliRope PE 4.5, 660', 5 lb............... #245100 $36.00 119
IntelliRope PE 4.5, 1320', 10 lb...........#245200 $72.00 119
EzeReel brkt for wood posts,1.50 lb..#238401 $11.85 129
MiniReel, 0.6 lb....................................#237600 $12.00 128
Two strands of IntelliRope supported by PowerPosts.
