A.
A
B.
F thru J E
E. Conductors F. SplitBall
Screw-In Ins.
G. XL Ring
Offset Ins.
H. SplitBall
Offset Ins.
D. Surge
Protector
C. 5-Light
Tester
J. ToggleWing
Eyebolt
I. Vinyl Line
Post Clip
Insert End Posts, 42"–48" Insert Line Posts, 30"–48"
(left) Illustrates how to attach the
insulator, P Spring and rope to a wood post.
K. P Spring Combination
1. 2. 3.
72 HORSE FENCES • 1-800-282-6631
Adding 1 or 2 energized strands
to any fence helps to protect
horses from a fence—and the
fence from the horse.
Place the electrified strand at the
height of your horse’s nose when
it walks.
The distance a strand should be
held away (offset) from a fence
varies. For vinyl or wood fences
2" is enough. However, because
the risk of injury is greater, for
HT wire fences we think the
maximum (7"-9") is best.
Uses
• Prevents horses fighting across
paddock fences.
• Keeps horses from leaning,
rubbing or chewing on fences.
• Enables worn and weary
fences to last a few more years.
• Gives longevity to new fences.
• Keeps horses away from less-
safe fences (HT, barbed wire).
• Carries pulses from an
energizer in the barn to
outlying fences.
Cost: as low as 9¢ per ft
The cost of a Guard Strand is
only the cost of the conductor,
insulators and energizer.
Which conductor? IntelliRope®
PE 4.5 works well and is less $$.
Which insulator? Depends
on the existing fence. Review
our insulators (pp. 130–135) and
choose those that match your line,
end and corner posts.
A single strand of electrified rope keeps horses from leaning on, reaching over, rubbing or chewing valuable fences. Note
its location behind the upper wood horizontal—aesthetically out of sight to people outside of the fence. If needed, add a
second (lower) conductor to deter foals, ponies and mini horses.
Fence diagram
Product Name Item Price Pg #
A. Battery, Plug-in or Solar Energizers .................................. 79
B. Ground Rod, 6' x 5/8", 6 lb...........#151000 $10.50 102
Stainless Clamp, 0.10 lb...............#151800 $1.55 102
C. 5-Light Tester, 0.24 lb...................#134100 $11.50 103
D. Surge Protector, 0.20 lb...............#156500 $11.50 103
E. EnduraSoft 6.0, 660', 12 lb..........#256500 $90.00 118
IntelliRope PE 6.0, 660', 8.20 lb...#256900 $54.00 118
IntelliRope PE 4.5, 660', 5 lb........#245100 $36.00 119
IntelliBraid, 660', 11.60 lb.............#256710 $100.00 118
IntelliTwine, 660', 2 lb...................#253500 $19.50 119
IntelliTape, 660', 3 lb.....................#257020 $32.00 120
F. SplitBall Screw-In Ins., 0.08 lb.....#380600 $0.77 131
Product Name Item Price Pg #
G. XL Ring Offset Ins., 0.20 lb.......#390500 $.96 133
H. SplitBall Offset Ins., 0.20 lb.....#390300 $1.12 133
I. Upper Vinyl Line Clip, 0.10 lb...#392005 $0.44 134
J. ToggleWing Eyebolt, 0.20 lb.....#392100 $2.01 134
K. P Spring Combination
1. TuffRing II Ins., 0.10 lb..........#380705 $0.64 132
2. P Spring, SS, 0.30 lb.............#255010 $2.95 137
3. RopeLink 2.6, 0.10 lb............#256210 $0.77 137
Items not shown
Product Name Item Price Pg #
PigTail Offset, Nail In, 0.55 lb.......#391600 $2.22 133
Lower Vinyl Line Clip, 0.05 lb......#392004 $0.50 134
