73 / 148
Anchor
Wire Anchor Strainer
actual size
close-up
1
2
Anchor and Strainer Anchors are inserted into end posts with EquiLine passing through them. They are held in position via strain from the EquiLine. Strainer Tool pulls EquiLine through the Anchor. Anchor, ea, 0.10 lb............................... #470001 $2.76 Wire Anchor Strainer Tool, 5 lb..........#470002 $110.00 Gripples Used to terminate EquiLine at an end post. Can also be used as a splice. They are quick, simple and effective. Also sold on p. 139. Gripple, large, 0.10 lb............................#336810 $2.30 Coupler Can be used to connect or splice 2 ends of EquiLine together. EquiLine is inserted into both ends and held via tension. Operates similar to a finger trap. Coupler, 0.10 lb ...................................#470003 $3.35 EquiLine Star It is not conductive. It will not rust, rot, corrode, fade, discolor or mildew. White. 0.15" diameter. EquiLine Star, 2000', 20 lb..................#470000 $269.00EquiLine Star is not as easy to tie with a knot as EquiLine
(1) because it is stiffer. Gripples (2) work very well with
EquiLine Star and are fast and effective.
What is it?
A high-strength polymer
monofilament horse fence material.
Key Features:
• Safe for horses.
• Requires very little maintenance
if tensioned adequately and the
posts are properly installed.
• Very attractive.
• Resists wind, snow, ice and time
better than all other safe horse
fence materials.
• Like all nonconductive horse
fences, adding an offset energized
wire keeps horses from leaning
on or reaching through it.
• Use proper anchors, splices and
tools for best results and faster
installation
(see at right).
Cost: as low as 68¢ per ft
Installation questions?
See detailed information on our website.
How does EquiLine Star differ
from EquiLine
?
1.
Much stronger.
2. Cross-sectional shape is
star-shaped
instead of round.
3.
Less affected
by UV light.
Other things to consider
Why is it safer than HT wire?
Because it is:
• Much larger.
• Much more visible.
• More elastic (flexes away from horses
on impact).
Couplers and ends?
(See at right.)
Tension?
By hand.
(See at right.)
Spacing between posts?
Up to 20 ft.
Line posts and end posts?
Same as for
electrified rope fences
(pp. 70–71)
.
How long will it last?
Fences installed
years ago are still as new. We don't
know of any that have failed so far.
EquiLine ™ StarPermanent
How to terminate at end posts
EquiLine Accessories
www.premier1supplies.com• 1-800-282-6631
HORSE FENCES 73
