78 / 148
I.
H.
A
B
F
E
G
L
45" +
29" +/-
15" +
J
I
J.
K.
O
K
C. 5-Light
Tester
D. Surge
Protector
E. Insulated
Cable
G. Conductor
H. - K. Posts
M. SnapOn
Harp Clip
N. PowerGrip
Clip
L. ScrewOn
Insulator
O. PigTail
Clip
Up to 40 ft between line posts
Insert
T Post 18"
Insert FiberRod
6"–12"
R. P Spring Combination
1. 2. 3.
Multi-RopeSemi-Permanent
Consists of up to 3 electrified strands of
IntelliRope
®
(either 6.0 or 4.5).
Differs from portable fences because it:
• Has more conductive strands.
• Uses rope instead of twine.
• Does not include windup reels
.
Why use rope instead of twine or tape?
Because it’s more visible than twine. And
it’s stronger and withstands wind, snow
and light ice storms better than twine,
polywire or tape.
The rope is hand-tensioned (to 25 to
40 lb) and supported by steel, wood or
FiberRod
™
line posts spaced up to 40 ft
apart. Steel T posts and wood line posts
are more expensive than FiberRods, but
they are stronger, can take more side
strain and are more reliable year-round.
End and corner posts are steel or wood.
The rope is pulled only hand-tight—which
makes this fence design superior to high
tensile wire fences for irregular fence lines
that curve or go up and down frequently.
The fence is also simple and rapid to
install and remove.
A wide-impedance energizer is advised
for 4-season fences—those that must work
when the grass stays brown or deep snow
covers the soil.
Uses
• To fence rented land.
• To subdivide pastures
for up to 5 yrs.
• Enclose cropland
for a season.
• As borders
for forests, streams, ponds.
• As an interim fence
until a more
permanent fence can be decided upon
and installed.
Cost: as low as 12¢ per ft
Three energized ropes supported by a step-in
PigTail post with 2 adjustable PigTail clips.
To install
Tools:
Cutters to cut conductors;
hand or power drivers to drive
in steel or small wood posts;
hammer to install nail-on
insulators; battery drill with
our power driver to rapidly
insert screw-in insulators.
Time:
Installing end and line
posts takes the majority (75%)
of the time. About 1000 ft in 2
hours in easy conditions.
Skill:
Simple, straightforward.
Fence diagram
Product Name
Item Price Pg #
A. Battery, Plug-in or Solar Energizers...................................79
B. Ground Rod, 6' x 5/8", 6 lb...........#151000 $10.50 102
Stainless Clamp, 0.10 lb................#151800 $1.55 102
C. 5-Light Tester, 0.24 lb...................#134100 $11.50 103
D. Surge Protector, 0.20 lb............... #156500 $11.50 103
E. Insulated Cable
136
F. Warning Sign, 0.06 lb...................#346000 $0.97 137
G. IntelliRope PE 6.0, 660', 8.20 lb.. #256900 $54.00 118
IntelliRope PE 4.5, 660', 5 lb.........#245100 $36.00 119
H. PowerPost, 48", 1.10 lb................ #320830 $4.80 124
I. FiberRod, 3/8" x 4', 0.38 lb..........#321841 $1.50 126
J. PigTail Post, 35", white, 1.40 lb... #320506 $3.05 125
K. Galv. Steel T Post, 6', 9 lb............. #327600 $12.90 127
Product Name
Item Price Pg #
L. ScrewOn Ins., 0.10 lb................... #325400 $0.29 134
M. SnapOn Harp Clip, 0.10 lb.............#325310 $0.19 134
N. PowerGrip Clip, 0.10 lb................. #325000 $0.15 134
O. PigTail Clip, 0.05 lb.........................#391700 $0.23 135
P. P Spring Combination
1. PI 21 Terminal Ins., 0.08 lb.......#369100 $0.45 132
2. P Spring, SS, 0.30 lb.................#255010 $2.95 137
3. RopeLink, 0.10 lb.......................#256210 $0.77 137
Items not shown
Product Name
Item Price Pg #
EzeReel Complete, 4 lb..................... #238600 $30.00 129
PI 21n Notched Ins., 0.08 lb.............. #369200 $1.03 132
Rope Connector, 0.06 lb................... #256200 $1.00 137
