Premier 1 2015 Fences That Work

76 / 148

D F
G
J
L
N
M
Post Options
_
+
_
+
_
34" +
E
22" +
K
H
I C
Insert FiberRod
6"–12"
Insert
T Post 18"
Insert Wood Posts
42"–48"
This temporary fence is attached to
an existing electrified permanent fence. Up to 25 to 40 ft between line posts
O
G. H. I. J.
A. 5-Light Tester B. Surge Protector D. Conductor Hook E. PowerLink F. Conductor G.–J. Posts K. PigTail
Clip
L. ScrewOn
Insulator
M. EzeReel N. EzeReel T
Post Bracket
Temporary
Up to 3 strands of IntelliTwine™ or
IntelliRope® supported by FiberRods
and step-in posts, wound, unwound and
tensioned with an EzeReel™.
Conductor ends are attached via
insulators to existing fences and charged
by a battery energizer or by attaching to
an existing hot wire.
For dry soil and snowy conditions, use
3 strands and convert fence to an earth-
return system (also called a Pos/Neg
system) by connecting the middle strand
to a galvanized stake driven into the soil.
Uses
• Subdivide pastures.
• Rotational grazing.
• Protect stored hay.
• Reduce access to streams and ponds.
• Guide cattle into temporary corrals.
Cost: as low as 11¢ per ft
Cost of line post varies by type of post.
Conductor cost:
• IntelliRope 4.5 is bulkier than twine,
lasts longer and costs more per ft. It’s
also more visible to all species.
• IntelliTwine costs the least. It’s very
easy to rewind. However, it’s less
visible than IntelliRope to all species.
To install
Tools: None if existing fences act as end
posts. A hammer may be necessary to
drive FiberRod posts into harder soils.
Time: 1000 ft in 30 minutes in easy
conditions with existing fences as end
posts. Fencing around/through brush
and trees takes more time, as do ends,
curves and corner posts.
Skill: Minimal. Set the posts; string rope/
twine; attach a suitable energizer.
EzeReels attached to a steel T post. Conductor
shown is IntelliTwine.
76 CATTLE FENCES • 1-800-282-6631
Fence diagram
Product Name Item Price Pg #
A. 5-Light Fence Tester, 0.24 lb................#134100 $11.50 103
B. Surge Protector, 0.20 lb........................#156500 $11.50 103
C. Warning Sign, 0.06 lb........................... #346000 $0.97 137
D. Conductor Hook, 0.08 lb......................#237400 $0.89 137
E. PowerLink 4.0, 30", 0.20 lb................. #335500 $4.50 137
F. IntelliRope PE 6.0, 660', 8.20 lb...........#256900 $54.00 118
IntelliRope PE 4.5, 660', 5 lb.................#245100 $36.00 119
IntelliTwine, 660', 2 lb.......................... #253500 $19.50 119
G. Step-In FiberRod, 48", 0.50 lb.............#321843 $3.25 125
H. PigTail Post, 35", white, 1.40 lb............#320506 $3.05 125
I. FiberRod Post, 3/8" x 4', 0.38 lb..........#321841 $1.50 126
J. Galv. Steel T Post, 6', 9 lb......................#327600 $12.90 127
K. PigTail Clip, 0.05 lb.................................#391700 $0.23 135
Product Name Item Price Pg #
L. ScrewOn Ins., 0.10 lb............................#325400 $0.29 134
M. EzeReel Complete, 4 lb.........................#238600 $30.00 129
N. EzeReel T Post Bracket, 1.70 lb............ #238501 $15.00 129
O. SnapOn Harp Clip, 0.10 lb.....................#325310 $0.19 134
Items not shown
Product Name Item Price Pg #
Battery, Plug-In or Solar Energizers 79
Galvanized Ground Rod 6' x 5/8", 6 lb......#151000 $10.50 102
Stainless Clamp, 0.10 lb..............................#151800 $1.55 102
Insulated Cable 136
PowerGrip Clips, 0.10 lb.............................#325000 $0.15 134
PI 21n Notched Ins., 0.08 lb.......................#369200 $1.03 132
