An IntelliRope on FiberTuff posts.
PRS-I 50 solar fence energizer.
K. T post C. 5-Light Tester D. Surge Protecto r E. Insulated Cable G. PowerLink 4.0H. Conductor
I. Step-In FiberRods J. FiberTuff O. EzeReel P. EzeReel Bracket M. PI 21n InsulatorUp to 25 ft between line posts
Insert
T Posts 18"
B
F
E
G
I
H
K
L
M
J
O
P
48"
27"
N
L. T Post Safety CapQ
A
R
Fence diagram
Product Name
Item Price Pg #
A. Battery, Plug-in or Solar Energizers.................................. 82 B. Galv. Rod 6' x 5/8", 6 lb................#151000 $10.50 98 Galv. Rod 3' x 1/2", 2.10 lb...........#151200 $5.15 98 Stainless Clamp, 0.10 lb...............#151800 $1.55 98 C. 5-Light Tester, 0.24 lb...................#134100 $11.50 99 D. Surge Protector, 0.20 lb.............. #156500 $11.50 99 E. Insulated Cable..................................................................140 F. Warning Sign, 0.06 lb....................#346000 $0.97 141 G. PowerLink 4.0, 0.20 lb................. #335500 $4.50 141 H. IntelliRope PE 4.5, 660', 5 lb........#245100 $36.00 122 IntelliRope PE 4.5, 1320', 10 lb... #245200 $72.00 122 I. Step-In FiberRod, 48", 0.50 lb.....#321843 $3.25 133 J. FiberTuff Post, 48", 1.10 lb..........#000000 $4.75 131 K. Galv. Steel T post, 6', 9 lb...............#327600 $12.90 128To install
Tools:
Driver for steel T posts.
Time:
400 ft in an hour or less.
Skill:
Minimal.
Installation:
1. Tie rope or tape to the end
post insulator.
2. Walk along fence with reel
and posts in hand. Allow rope
or tape to unroll as you walk.
3. Every 25 ft, push in a post.
Clip the rope or tape in place.
At the far end attach reel and
tension rope or tape.
4. Attach energizer. Turn it on.
Check fence for voltage.
The least expensive horse fence design.
It’s also very easy to install and remove.
Consists of 1 or 2 strands of electrified
rope (IntelliRope
®
PE 4.5 or 6.0) or
IntelliTape
™
stretched hand-tight
between small-diameter wood, steel
or large fiberglass posts (usually
hand-driven).
Line posts are FiberTuff (w/clips)
or Step-In FiberRods. T-posts used as
support at corners/ends.
Uses
• To separate
horses from each other.
• To fence horses out of hazards.
• To make horses easier to catch
by
limiting the pasture size to only a
few days’ worth of grazing.
• To reduce under and overgrazing.
Rope or Tape Fence
Temporary
Cost: as low as 18¢ per ft
The cost is driven by the type and
number of rope strands used and choice of
energizer. The cost per ft for line posts is
the same for any number of strands.
Other notes
•
Horses must see a fence in order
to avoid it.
Our conductors have
contrasting black/white colors to
ensure that they
stand out visually
against
all
light or dark backgrounds.
• Conductivity is important. Ropes and
tapes that are poor conductors (often
found in farmstores) provide a strong
shock near the energizer and
a weak
shock at the far end of the fence.
• Good conductors provide a uniform
shock and allow the use of smaller
energizers (and so less cost and risk).
• Use step-in posts—either FiberTuff or
Step-In FiberRods with added clips.
• Fences must
always
be properly
energized. Don’t take chances!
Product Name
Item Price Pg #
L. T Post Safety Cap, 0.06 lb..............#381010 $0.42 139 M. PI 21n Notched Ins., 0.08 lb...........#369200 $1.03 136 N. PI 21 Terminal Ins., 0.08 lb.............#369100 $0.45 136 O. EzeReel, 4 lb....................................#238600 $30.00 125 P. EzeReel Bracket—T posts,1.70 lb...#238501 $15.00 125 Q. SnapOn Harp Clip, 0.10 lb..............#325310 $0.19 133R. FiberTuff 19 Single Clip, 0.15 lb.....#208800 $0.30 131
Items not shown
Product Name
Item Price Pg #
IntelliTape, 330', 2 lb..........................#257010 $16.00 123 IntelliTape, 660', 3 lb......................... #257020 $32.00 123 IntelliTape, 1320', 6 lb....................... #257040 $64.00 123 EzeReel brkt for wood posts,1.50 lb..#238401 $11.85 125 MiniReel, 0.6 lb....................................#237600 $12.00 12564 HORSE FENCES
