65 / 152
48"
36"
24"
12"
12"
24"
12.5" between posts,
built-in
(DS) =
Double
Spike
Posts
What is it?
A ready-to-install electrifiable mesh
that takes only minutes to erect. Line
posts are already built into each roll.
Specifications
Posts are 3/4" diameter with a steel
double-spiked foot. They’re spaced
every 12.5 ft.
Mesh is 4 ft tall when installed. It’s
suspended 1 ft above the soil.
The 4 conductive horizontal strands
are 3/16" diameter.
The unique plastic
verticals (every 2 ft) are designed to
break if a horse challenges the fence.
How large a fence energizer?
Most QuikFence fences need an
energizer with 0.15 to 1.5 joules.
See pp.
76–99 for energizer options and details.
Horse QuikFence ® 4/48/24 50' x 48" (DS), 10 lb.............................................. #208021 $76.00 100' x 48" (DS), 17 lb.................................................#208022 $124.00Energizers & Recommended Accessories
Product Name
Item Price Pg #
Battery, Plug-in or Solar Energizers.................................................. 82 5-Light Tester, 0.24 lb...............................#134100 $11.50 99 Warning Sign, 0.06 lb...............................#346000 $0.97 141 FiberTuff Post, 48", 2 lb............................ #208055 $4.75 131 Horse QuikFence ® 4/48/24 Semi-PermanentAre extra posts needed?
The built-in posts are adequate for
line, curve and corner posts.
But extra support at ends may be
required. For this, use small wood
or steel posts or string tied from
the post tops back to tent pegs.
FiberTuff
™
(p. 131)
posts are also
recommended for support.
Pros
• Attractive, safe fence.
• Very visible.
• Effective, no-worry barrier.
• Installs with ease up/down hills,
across valleys, around curves and
next to trailers.
• Also stops cattle, camelids and
most deer.
• Ideal for subdivision fences, semi-
permanent boundary fences and
as a weekend fence for shows and
trail rides.
Cons
•
Must
be properly energized!
Cost: as low as $1.24 per ft
(above) Horse QuikFence as a perimeter fence
for grazing between an existing fence and building.
Subdivision fence in background is single-strand
conductor on Pigtail posts.
(above) Horse QuikFence works easily to
build trailer paddocks. End posts are tied (with
nonconductive strings) to the trailer for support.
Make sure the posts/net do not touch the trailer.
To install
1. Untie the strings.
2. Unroll and then unfold the mesh.
3. Step on the double spikes to
insert the posts into the ground.
4. Stretch the fence hand-tight.
5. Attach an energizer.
www.premier1supplies.com • 1-800-282-6631HORSE FENCES 65
