68 / 152
60"
48"
36"
24"
12"
Up to 35 ft between line posts
H
A
F
G
B
E
I
J
K
L
Insert T
Posts 18"
Insert Line Wood
Posts 42"–48"
Insert End and Corner
Wood Posts 42"–48"
C. 5-Light Tester D. Surge Protector E. Insulated CableH. Conductor
I. Galv. Steel T Post K. Premier Combo Ins.J. Premier
Hot Top Ins.
L. Corner Post Ins. M. Wood Line Post Ins.To install
1. Install end, corner & line posts.
2. Attach insulators to posts.
3. Attach rope to one end post.
4. Clip rope into insulators.
Pull until the P Spring is 50%
compressed. Terminate it.
5. Connect ropes electrically at one
end with an insulated wire or a
Rope-to-Rope Link.
6. Install and connect the
energizer. Voltage should be
over 1500 volts. The fence must
always be properly electrified.
Popular due to its:
• Low cost.
• Ease and speed of installation
compared to other fences.
It consists of up to 5 strands of
electrifiable, long-lasting IntelliRope,
EnduraSoft or IntelliBraid strained
between wood end and corner posts and
supported by wood or steel line posts.
Spacing of line posts (not more than 35
ft) must be adjusted to the terrain. Always
put a post on top of hills and at the bottom
of valleys.
Vary the spacing of rope strands
according to type and size of horse(s),
fence usage (boundary vs subdivision)
and the number of strands used.
Must always be properly energized.
Horses have long memories.
So never allow them a chance to suspect
that a fence might not be electrified.
Fence diagram
Product Name
Item Price Pg #
A. Battery, Plug-in or Solar Energizers.....................................82 B. Galv. Ground Rod, 6' x 5/8", 6 lb.. #151000 $10.50 98 Stainless Clamp, 0.10 lb................ #151800 $1.55 98 C. 5-Light Tester, 0.24 lb.................... #134100 $11.50 99 D. Surge Protector, 0.20 lb.................#156500 $11.50 99 E. Insulated Cable.................................................................... 140 F. Warning Sign, 0.06 lb.................... #346000 $0.97 141 G. Cut-Out Switch, 0.32 lb.................#333000 $7.50 141 H. EnduraSoft 6.0, 660', 12 lb............#256500 $90.00 122 IntelliRope PE 6.0, 660', 8.20 lb....#256900 $54.00 122 IntelliBraid, 660', 11.60 lb.............. #256710 $100.00 122 I. Galv. Steel T Post, 7', 10.50 lb.......#327800 $14.15 128 J. Premier Hot Top Ins., 0.20 lb.........#381000 $0.75 134Rope Fences
Permanent
Uses
•
Boundary fence.
An attractive, effective,
low-cost option to vinyl and wood fences.
• Subdivide pastures and feeding areas
.
Enables feeding and pasturing horses
as individuals. Reduces horse-to-horse
bonding problems.
• To keep horses from hazards.
Examples are feed, stored building
materials and frozen ponds and streams.
• To fence floodplains.
Floodwaters flow
through rope fences more readily than
other fences. And rope is easier to repair
if a serious flood occurs.
• To prevent horses in adjacent pens
from having physical access to each
other.
Nothing works as well for this as a
high-quality electric fence.
Cost: as low as 45¢ per ft
Factors that affect costs are:
• Choice of energizer.
• Choice of rope.
• Number of strands.
Both mares and their foals quickly learn to respect
a 5-strand electrified rope fence.
Product Name
Item Price Pg #
K. Premier Combo Ins., 0.10 lb...........#380321 $0.28 135 L. Corner Post Ins., 0.20 lb................#380900 $0.96 136 M. Wood Line Post Ins., 0.10 lb...........#380712 $0.30 135N. P Spring Combination
1. TuffRing II Ins., 0.10 lb................ #380705 $0.64 136 2. P Spring, SS, 0.30 lb...................#255010 $2.95 141 3. RopeLink 2.6, 0.10 lb..................#256210 $0.77 141 O. Rope Tensioner/Ins., 0.15 lb......... #255020 $0.81 135Items not shown
Product Name
Item Price Pg #
Rope Connector 1.0, 0.06 lb................ #256200 $1.00 141 Rope-to-Rope Link, 0.28 lb...................#335610 $4.80 14168 HORSE FENCES
